H01N2-D
REPS
Product Description
These cables are used as a connection to welding robots in the automotive industry, shipyards and for manually/automatically operated lines and spot welding. These cables are ideal for use as an interconnecting battery cable or in battery storage systems. The robust cable structure makes them resistant to low and high temperatures, ozone and radiation, oils, acids, fats and petrols.
Technical Data
CONSTRUCTION
1: Conductor
Generally to Class 6 flexible copper conductor
2: Separator
PET (Polyester Tape)
3: Sheath
Rubber compound
Sheath Colour
Black Red
CHARACTERISTICS
Voltage Rating
100V
Temperature Rating
Fixed: -40°C to +85°C
Flexed: -20°C to +85°C
Minimum Bending Radius
Flexed: 6 x overall diameter
Dimensions
| Number of cores and nominal cross section | Copper figure | Wire diameter | Insualion thickness | Overall diameter | Weight |
| mm² | kg/km | mm | mm | appr.mm | appr. kg /km |
| 1x 16 | 160 | 21 | 20 | 95 | 210 |
| 1x 25 | 250 | 21 | 20 | 110 | 300 |
| 1x 35 | 350 | 21 | 20 | 120 | 400 |
| 1 x 50 | 500 | 21 | 20 | 140 | 560 |
| 1x 70 | 700 | 21 | 24 | 165 | 780 |
| 1x 95 | 950 | 21 | 26 | 185 | 1.010 |
| 1x120 | 1.200 | 51 | 28 | 200 | 1.250 |
