Technical Data
Temperature range:
• During application with bending: -25 °C up to +60 °C
• Fixed installed: -40 °C up to +80 °C
• At short circuit of max. 5 s: up to 200 °C
Nominal voltage: U0 /U = 0,6/1 kV
Test voltage: 2500 V
Maximal permitted voltage:
• In AC installations: U0 /U = 0,7/1,2 kV
• In DC installations: U0 /U = 0,9/1,8 kV Specific el. resistance of insulation: min. 10 MΩ x km
Maximal tensile strength:
• Static: 15 N/mm2
• Dynamic: 30 N/mm2
Conveyor speed : up to 120 m/min
Other characteristics:
• Resistance to oil, moisture, water, UV-irradiation, ozone, solvents, greases, alkali, gasoline, weather conditions
Behaviour in fire: Flame retardant (self-extinguishing) cable acc. to IEC 60332-1 / EN 60332-1 (earlier EN 50265-2-1) / VDE 0482-332-1 (earlier VDE 0482-265-2-1, also DIN VDE 0472 part 804 test method B)
Construction
1. Conductor: tinned copper conductor, fine wired stranded, class 5 acc. to IEC 60228 / HD 383 / DIN VDE 0295
2. Insulation: rubber compound on ethylene-propylene basis (EPM, earlier: EPR), i.e. 3GI3 or GI1 acc. to DIN VDE 0207 part 20
• Concentrically stranded cores in layers
3. Insulated: steel suspension core could also be laid in the cable center to prevent cable elongation
4. Core layers could be wrapped with tape
5. Inner sheath: rubber compound on poly-chloroprene basis (CR), i.e. 5GM3 acc. to DIN VDE 0207 part 21
6. Textile braid: fitted in inner or external sheath to prevent cable torsion 7. Sheath: rubber compound on poly-chloroprene basis (CR) (= Neoprene), i.e. 5GM2 or 5GM3 acc. to DIN VDE 0207 part 21.
7. Sheath colour: black Core colour marking: acc. to HRN HD 308 S2 / VDE 0293-308
